Minimum Requirements for Installing Onepoint

1. Minimum Requirements for Onepoint

Before installing onepoint, you should verify the following requirements for a production or stress-test environment:

1.2 Minimum Hardware Requirements (Physical or Virtual)

  • OS: CentOS 7
  • Database: MariaDB 10 or later OR MySQL 8 or later
  • Third-party repositories:

– epel-release You can install it running the following command:

 ]# yum install epel-release

– Remi’s Repository You can install it running the following command:

 ]# yum install https://rpms.remirepo.net/enterprise/remi-release-7.rpm
  • Apache: v2.4 or later

You can install it running the following command:

 ]# yum install httpd
  • PHP: v7.2 or later with the following extensions:
    • php72-php
    • php72-php-common
    • php72-php-bz2
    • php72-php-curl
    • php72-php-ldap
    • php72-php-gd
    • php72-php-gmp
    • php72-php-imap
    • php72-php-mbstring
    • php72-php-mcrypt
    • php72-php-soap
    • php72-php-mysqlnd
    • php72-php-xml
    • php72-php-zip
    • php72-php-json

You can install them running the following command (once Remi is installed):

 ]# yum install php72-php php72-php-common php72-php-bz2 php72-php-curl php72-php-ldap php72-php-gd php72-php-gmp php72-php-imap php72-php-mbstring php72-php-mcrypt php72-php-soap php72-php-mysqlnd php72-php-xml php72-php-zip php72-php-json

  • Python: v2.7 with the following packages:
    • python
    • python-pip
    • python-requests
    • python-ldap
    • python-paramiko

You can install them running the following command:

 ]# yum install python-pip python-ldap python-paramiko
  • Runtime Libraries:
    • curl
    • curlpp

You can install them running the following command:

 ]# yum install curl http://download-ib01.fedoraproject.org/pub/epel/6/x86_64/Packages/c/curlpp-0.7.3-5.el6.x86_64.rpm
    • libssh
    • json-c
    • json-cpp

You can install them running the following command:

 ]# yum install libssh json-c jsoncpp
  • Other tools:
    • psutils
    • psmisc
    • telnet (Client)
    • SSH Server
    • SSH Client
    • SAMBA

You can install them running the following command:

 ]# yum install psutils psmisc telnet ssh

1.3. Minimum Network Requirements

Outbound ports: Onepoint machine needs to access the managed assets in their respective protocols:

  • LDAP / Active Directory: 389/tcp, 636/tcp; privileged account for the instance
  • Windows Servers: 135/tcp, 445/tcp; privileged local or domain account for the machines
  • Linux Servers: 22/tcp; privileged account for the machine
  • MySQL/MariaDB: 3306/tcp; privileged account for the instance
  • PostgreSQL: 5432: privileged account for the instance

2. Licensing considerations

After registering on our website you will until 24 hours receive a license file with instructions on how to install. For using and updating the product, and having access to its features, you will need to install this license.

3. Package Repository

Installation

  1. Installing Onepoint on CentOS 7 with Hashicorp Vault for instructions on how to install it to work together with Hashicorp Vault
  2. Installing Onepoint on CentOS 7 for using Internal Vault Backend
